Modbus RTU/RS485 Communication Protocol CT PT Metering Unit for 50Hz/60Hz Frequency and 12/42/75kv Rated Insulation Level

Product Description:

The CT PT Metering Unit is a versatile device designed for accurate and efficient current and voltage protection in various electrical applications. With its LCD/LED display type, this unit offers clear visibility of critical information, ensuring easy monitoring and control of electrical parameters.

Operating at a rated voltage of up to 1000V, the CT PT Metering Unit is capable of handling high voltage levels with precision and reliability. This makes it suitable for a wide range of industrial and commercial settings where robust performance is essential.

Equipped with Modbus RTU/RS485 communication protocol, this metering unit allows seamless integration with other monitoring systems for enhanced data collection and analysis. The communication protocol ensures compatibility with different devices, enabling easy data exchange and remote monitoring capabilities.

The CT PT Metering Unit is specifically designed for current and voltage protection, offering comprehensive safeguarding features to prevent damage to electrical equipment and ensure safe operating conditions. Its advanced protection mechanisms make it an essential component in maintaining electrical system integrity and reliability.

With a temperature range of -25°C to +55°C, this metering unit is engineered to withstand extreme environmental conditions without compromising performance. Whether in hot or cold environments, the CT PT Metering Unit continues to deliver accurate measurements and reliable protection for uninterrupted operation.

Features:

• Product Name: CT PT Metering Unit
• Rated Insulation Level: 12/42/75kV
• Accuracy Class: Class 0.2, 0.5, 1.0, 3.0
• Frequency: 50Hz/60Hz
• Communication Protocol: Modbus RTU/RS485
• Display Type: LCD/LED

Technical Parameters:

Applications:

The CT PT Metering Unit is a versatile product designed for a wide range of applications where current and voltage protection is crucial. Its measurement type, utilizing both Current Transformers (CT) and Potential Transformers (PT), allows for accurate monitoring and control of electrical systems.

With a toroidal coil structure, the CT PT Metering Unit offers reliable performance and efficient operation. The insulation level of up to 12kV ensures safety and protection in high-voltage environments, making it suitable for use in various industrial settings.

The CT PT Metering Unit is available in different accuracy classes, including Class 0.2, 0.5, 1.0, and 3.0, catering to specific precision requirements of different applications. Whether it is for critical measurements that demand high accuracy or general monitoring purposes, this product delivers consistent and dependable results.

Product Application Occasions and Scenarios:

- Power Distribution Systems: The CT PT Metering Unit is ideal for monitoring current and voltage levels in power distribution systems, ensuring efficient and safe operation.

- Renewable Energy Plants: In renewable energy plants such as solar or wind farms, the CT PT Metering Unit can be used to measure and protect electrical components, optimizing energy production.

- Industrial Facilities: From manufacturing plants to large industrial facilities, the CT PT Metering Unit provides essential data for maintaining operational efficiency and preventing electrical faults.

- Commercial Buildings: For monitoring electrical systems in commercial buildings, the CT PT Metering Unit offers a reliable solution for ensuring power quality and safety.

- Substation Monitoring: The CT PT Metering Unit is well-suited for use in substation monitoring applications, where accurate current and voltage measurements are essential for grid stability and reliability.

Customization:

Product Customization Services for the CT PT Metering Unit:

Voltage Class: 10kv

Display Type: LCD/LED

Protection Level: IP65

Communication Protocol: Modbus RTU/RS485

Measurement Type: Current Transformer (CT) And Potential Transformer (PT)

Support and Services:

The CT PT Metering Unit product offers comprehensive Product Technical Support and Services to ensure optimal performance and customer satisfaction.

Our technical support team is available to assist with any inquiries, troubleshooting, or maintenance needs related to the CT PT Metering Unit.

We provide timely assistance and guidance to help customers make the most of their investment in our product.

Additionally, we offer various services such as installation support, training programs, and product upgrades to enhance the user experience and maximize efficiency.

Packing and Shipping:

Product: CT PT Metering Unit

Description: High-quality CT PT Metering Unit for accurate power measurement.

Packaging: The CT PT Metering Unit is carefully packed in a sturdy cardboard box to ensure safe delivery.

Shipping: We offer fast and reliable shipping services to deliver the CT PT Metering Unit to your location.

FAQ:

Q: What is a CT PT Metering Unit?

A: A CT PT Metering Unit is a device used to measure and monitor electrical parameters in a power system. It consists of Current Transformers (CTs), Potential Transformers (PTs), and associated metering components.

Q: How does a CT PT Metering Unit work?

A: CTs step down high currents flowing through power lines to a measurable level, while PTs step down high voltages to a safe level for meters. The metering components then calculate and display the electrical parameters based on the transformed values.

Q: What are the key features of the CT PT Metering Unit?

A: Key features may include accurate measurement, high insulation levels, multiple ratios for different applications, compact design, and compatibility with various metering systems.

Q: How is a CT PT Metering Unit installed?

A: Installation involves mounting the CTs and PTs at appropriate locations in the power system, connecting them to the metering components, ensuring proper wiring and insulation, and calibrating the unit for accurate readings.

Q: What are the common applications of a CT PT Metering Unit?

A: CT PT Metering Units are commonly used in substations, industrial plants, commercial buildings, and utility grids to monitor power consumption, power quality, load management, and for billing purposes.
